Industrial. Agricultural. Commercial. Canadian Lighting Manufacturer
The LZ Series Standard Body 4’ fixture is a renowned vaportight fixture, ideal for applications needing extensive coverage on low to high ceilings. It offers versatility with multiple lumen packages and mounting options, featuring various latch and lens styles. The casing is made in the USA with a robust build and a thick seal for durability in dusty or wet environments, it suits installation heights from 12 to 22 feet. Final assembly in Ontario, Canada ensures meticulous craftsmanship, making it the ideal lighting solution for your needs
This unit excels in industrial, commercial, and agricultural settings where protection against water and dust is essential. It performs exceptionally in demanding applications including wash bays, dairy barns, sheep barns, horse barns, pig barns, welding facilities, concrete plants, car washes, and numerous other challenging environments, making it an exceptional choice for the most demanding conditions.
Approved for use in Canada and USA, QPS certified.
Includes standard 5-year warranty-view our warranty policy for complete details.
| CRI | CCT | Lumens |
|---|---|---|
| 8C 80 | 30K 3000K | 190L 19,000 |
| 9C 90 | 40K 4000K | 170L 17,000 |
| - | 50K 5000K | 150L 15,000 |
| - | 65K 6500K | 114L 11,400 |
| - | - | 085L 8,500 |
| - | - | - |
| Voltage | Driver | 0-10V Wiring |
|---|---|---|
| UNV 120-277V | D1 0-10V 1% | NW Not Wired For Dim |
| 347 347V | - | PW Pre-Wired for DIM |
| - | - | - |
| - | - | - |
| - | - | - |
| - | - | - |
| Lens | Mounting | Options |
|---|---|---|
| CR Clear Ribbed | MB Surface/Chain Mount Brackets | Blank None |
| FR Frosted Ribbed | NM No Mount Brackets | RTP Retail Packaging |
| CS Clear Smooth | - | CD2 2’ Whip Pre-Wired (Black) |
| FS Frosted Smooth | - | CD3 3’ Whip Pre-Wired (Black) |
| - | - | - |
| - | - | - |
| CRI | CCT | Lumens |
|---|---|---|
| 8C 80 | 30K 3000K | 190L 19,000 |
| 9C 90 | 40K 4000K | 170L 17,000 |
| - | 50K 5000K | 150L 15,000 |
| - | 65K 6500K | 114L 11,400 |
| - | - | 085L 8,500 |
| - | - | - |
| Voltage | Driver | 0-10V Wiring |
|---|---|---|
| UNV 120-277V | D1 0-10V 1% | NW Not Wired For Dim |
| 347 347V | - | PW Pre-Wired for DIM |
| - | - | - |
| - | - | - |
| - | - | - |
| - | - | - |
| Lens | Latches | Mounting | Options |
|---|---|---|---|
| CR Clear Ribbed | PM POM (Nylon) | MB Surface/Chain Mount Brackets | Blank None |
| FR Frosted Ribbed | SS Stainless Steel | NM No Mount Brackets | RTP Retail Packaging |
| CS Clear Smooth | - | - | CD2 2’ Whip Pre-Wired (Black) |
| FS Frosted Smooth | - | - | CD3 3’ Whip Pre-Wired (Black) |
| - | - | - | - |
| - | - | - | - |
| CRI | CCT | Lumens |
|---|---|---|
| 8C 80 | 30K 3000K | 190L 19,000 |
| 9C 90 | 40K 4000K | 170L 17,000 |
| - | 50K 5000K | 150L 15,000 |
| - | 65K 6500K | 114L 11,400 |
| - | - | 085L 8,500 |
| - | - | - |
| Voltage | Driver | 0-10V Wiring |
|---|---|---|
| UNV 120-277V | D1 0-10V 1% | NW Not Wired For Dim |
| 347 347V | - | PW Pre-Wired for DIM |
| - | - | - |
| - | - | - |
| - | - | - |
| - | - | - |
| Lens | Mounting | Options |
|---|---|---|
| CR Clear Ribbed | MB Surface/Chain Mount Brackets | Blank None |
| FR Frosted Ribbed | NM No Mount Brackets | RTP Retail Packaging |
| CS Clear Smooth | - | CD2 2’ Whip Pre-Wired (Black) |
| FS Frosted Smooth | - | CD3 3’ Whip Pre-Wired (Black) |
| - | - | - |
| - | - | - |
